Freno de rotor principal

Riferimento: 87/20

Actuating lever

The connection between mixer lever and variable rocker is carried out by an actuating lever, triple ballraced. Content of the package: 2 pieces

Riferimento: 702/10

Corpo centrale Elastomero

Elastomer 2-blade-centre piece, GRP.

Riferimento: 702/79

Flybar stainless steel 5 x 270 mm

Pack of 2

Riferimento: 832/76

Blade holder, 22 mm

Blade holder, 22 mm, alone

Riferimento: 117/3

Spacer washer 10 x 24.6 mm

Spacer washer for rotor headPack of 2

Riferimento: 76/9

Portapala

Blade holder arm, aluminium. Content of the package: 1 piece.

Riferimento: 703/340

Washer for fastening multi-blade head

Not available

Riferimento: 76/19

GRP blade holder, 5 mm ∅ hole

As demands on helicopters continue to rise, so stronger blade holders are required. In this case a 14 mm blade holder is combined with a 5 mm Ø hole for blade retention, i.e. the matching blade holder screws and self-locking nuts are M5 in size.GRP blade holder with short linkage armfor multi-blade rotor heads

Riferimento: 82/31

Bilanciere, VTR

Rocker, GRP, for rotor head 702/70, alone

Riferimento: 703/72

Eje de rodamiento de cuchillas para cabezal de 3 cuchillas

Riferimento: 73/10

Albero porta pale 8 x 110 mm

 Thrust bearing shaft8 Ø x 110 mm

Riferimento: 832/78

Mixer lever, aluminium

This mixer lever from aluminium matches the dimensions of the rotor head 722/72 (e.g. model Robinson R22) with a max. rotor disc of 2 500 mm.

Riferimento: 74/10

Anello 3 x 7 mm. duro

O-ring 3 x 7 mm hard Content of the package: 4 pieces Tip: O-rings always slide with a drop of silicone oil onto the shaft.

Riferimento: 74/3

O-ring 1 x 4 mm soft

content of the package: 8 pieces

Riferimento: 78/41

Mixer lever cranked

Mixer lever, content of the package 1 piece.Additionial accessories for the use of mixer levers are either two flanged ballraces or two flanged bushes from Delrin as a low cost alternative. The screwing on the blade holder arm complies with the kind of hole, i.e. it depends on the through hole or on the blind hole. Please note for choosing the screws:...

Riferimento: 87/4

Bielle Hiller a 90°

A 90° twisted double ball-link connect the mixer lever to the ball collet on the flybar. Content of the package: 2 pieces
