Rotula doble de para varilla estabilizadora

Reference: 74/5

O-ring 3 x 7 mm soft

O-ring 3 x 7 mm soft Content of the package: 4 pieces Tip: O-rings always slide with a drop of silicone oil onto the shaft.

Reference: 71 A

Centre piece for pitch compensatorOrd.No. 71 A

Centre piece for pitchcompensator, GFK, alone.

Reference: 832/78

Mixer lever, aluminium

This mixer lever from aluminium matches the dimensions of the rotor head 722/72 (e.g. model Robinson R22) with a max. rotor disc of 2 500 mm.

Reference: 72/45

Aluminium centre piece, 12 mm

Aluminium centre piece for 12 mm Ø main shaft

Reference: 54/13

Clamp ring pitch compensator 10 mm

On longer rotor shafts the clamp ring for the pitch compensator sits underneath of the centre piece directly on the rotor shaft.Clamp ring for pitch compensator 10 mm Ø, length of the pin 30 mm.

Reference: 71/18

Spacer for pitch compensator 2.8 x 5 x 2 mm

 Content of the package2 pieces

Reference: 87/4

Double ball-link, 90°

A 90° twisted double ball-link connect the mixer lever to the ball collet on the flybar. Content of the package: 2 pieces

Reference: 703/41

La palanca acodada, Alu

Reference: 82/30

Rocker kit Bell UH / Bell 212 / Bell 47

Not available

Reference: 79/15

Flybar stainless steel 4 x 600 mm

The length of the flybar itself also plays an important role in the model's flight characteristics: the longer the flybar, the smoother the hover. A longer flybar increases the control deflections. 450 mm length is considered normal, while 510 mm provides more docile handling.

Reference: 72/18

Rotor head centre piece, rigid

Aluminium centre piece, rigid, for 10 mm main shaft

Reference: 76/8

Ballrace spacer, steel

Ballrace spacer, steel Content of the package: 1 piece.

Reference: 86

Ball collet 4 mm

Ball collets provide the fixation of double ball-links on the flybar, in order to settle the essential distance to the rocker. Ball collet 4 mm Ø, pack of 2, chrome-plated.

Reference: 82/32

Washer for variable rocker 4 mm

Washer for variable rocker 4 mmContent of the package: 2 pieces

Reference: 702/76

GRP blade holder, 22 mm blade throat

This blade holder was specially developed for the large Bell 47 G III with a rotor diameter of 2.36 m. It has a 22 mm blade throat and a 6 mm Ø bore for the retaining screw, i.e. the matching blade holder screws and self-locking nuts are M6 in size.

Reference: 82/31

Rocker, GRP

Rocker, GRP, for rotor head 702/70, alone
