Heckrotorgehäuse

Riferimento: 92/38

Gehäusedeckel lang

Riferimento: 92/36

Coperchio per carter coda, alluminio

Aluminium cover for tail rotor housing for aluminium tail rotor with 6 mm shaft.

Riferimento: 99/6

Distanziale rotore coda

 Control ringfor tail rotor shaft 6 mm ∅

Riferimento: 95/7

Ingranaggio conico 5 mm, 19 denti

  Bevel gear 5 mm 19 tooth module 0.8

Riferimento: 100/7

Spina 2 mm per trascinatore

Content of the package: 2 pieces.

Riferimento: 92/37

Coperchio per carter coda, VTR

Housing cover for aluminium tail rotor with 6 mm shaftaluminium

Riferimento: 98/15

Boccola scorrevole per coda

 Control sleevefor tail rotor shaft 5 mm ∅with nut (left-hand thread!)

Riferimento: 103/6

Porta pale coda, tre parti

 Tail blade holder3-partfor 6 mm ∅ hub

Riferimento: 92/80

Set per ampliamento del rotore di coda a tre pale

Scale tail rotor fittings set, complete as illustrated

Riferimento: 34/5

Calettatore di passo per rotore di coda

The tail rotor blade pitch gauge is the perfect tool for setting pitch angles really accurately; the pitch range should be plus / minus 12°. The gauge can be used to set up any blade with a chord between 21 and 42 mm. It can also be employed for measuring pushrods and similar items up to a length of 110 mm.

Riferimento: 95/10

Spiral tooth bevel gears 17 t. Ø 5 mm + 16 t. Ø 5 mm

Not available

Riferimento: 94/16

Albero rotore di coda 6 x 92 mm

 Tail rotor shaft6 x 92 mm

Riferimento: 94 C

Seeger per albero Ø 5 mm

 Circlip for 5 mm ∅ shaftpack of 2

Riferimento: 97/13

Heckrotorumlenkhebel rechts verstärkt

Riferimento: 92/10

Carter rotore di coda

The advantage of this 2-part tail rotor housing is that the gearbox can be checked just by removing the rear housing shell. When adjusting the meshing clearance of the bevel gears and similar settings please keep closely to the building instructions; for lubrication use titanium grease; Ord.No. 10/36.The tail rotor is a vital and highly stressed component...

Riferimento: 97/5

Molle per rotore coda

The linkage of the tail rotor is affected by the face clearance of servo gears, by the bellcrank and by the pushrod. Minimal play can arise from the face clearance of the servo gears as well as from the necessary freedom of movement for the ball at the bellcrank.With the screw fitting pushrod connector the pushrod still is adjusted without play. The face...
