Set pesos ficticios estabilizadora Bell 47G

Référence: 87/21

Washer for actuator arm 2.5 x 9 mm

Washer for actuator arm Content of the package: 2 pieces

Référence: 76/16

GRP blade holder, 5 mm ∅ hole

As demands on helicopters continue to rise, so stronger blade holders are required. In this case a 14 mm blade holder is combined with a 5 mm Ø hole for blade retention, i.e. the matching blade holder screws and self-locking nuts are M5 in size.GRP blade holder with long linkage armfor two-blade rotor heads

Référence: 832/69

Connecting elbow, aluminium

Connecting elbow, aluminiumPack of 2

Référence: 54/13

Clamp ring pitch compensator 10 mm

On longer rotor shafts the clamp ring for the pitch compensator sits underneath of the centre piece directly on the rotor shaft.Clamp ring for pitch compensator 10 mm Ø, length of the pin 30 mm.

Référence: 117/20

Thrust bearing set complete

The standard version of our mechanics includes ground thrust bearing shafts with a of 8 mm Ø and a length of 110 mm.Thrust bearings absorb the high centrifugal forces exerted by the main rotor blades. The effect of the axial bearings is retained in full when the blade holders rotate.Thrust bearing set, complete as shown.

Référence: 91/50

Palettes

Paddles1 pairapprox. 29 g eachfor ∅ 4 mm / 5 mm flybar

Référence: 703/45

Rotor head linkage for Alouette III

This rotor head linkage is essential for the correct operation of the rotor head of the Alouette III due to its heavy take-off weight.

Référence: 82/52

Spacer washer for SKS rotor head

Spacer washer for SKS rotor head Content of the package: 2 pieces

Référence: 80/30

Bras de commande en métal, 5 mm

Control bridge 2-part metal, for 5 mm ∅ flybar.

Référence: 707/3

Rotor head cover for 3-blade head

155 mm diameter

Référence: 76/15

Porte-pales GFK

Blade holder, GRP, reinforced

Référence: 68/22

Aluminium side frames

Aluminium side frames for swashplate driver 68/20 and 68/50. Content of the package: 2 pieces

Référence: 76/20

Blade holder set, aluminium

On all 2-blade rotor heads up to 1800 mm rotor disc different blade holders can be mounted.Blade holder set, for one blade holder

Référence: 703/72

Eje de rodamiento de cuchillas para cabezal de 3 cuchillas

Référence: 76/25

Blade holder, blade grip 18 mm

Not available

Référence: 702/15

15mm 2 blade centre piece

Aluminium centre piece for 15 mm Ø main shaft
