Bilanciere, VTR

Référence: 832/75

Thrust washer

Thrust washer for rotor head Content of the package: 2 pieces

Référence: 80/10

Cadre de commande, boules métal

The control bridge actuates the flybar. The servos pass the control commands to the swashplate. The collective pitch compensator connected to the swashplate transfers the movement to the control bridge via the angled pushrods. The flybar accepts the control commands and passes them on to the blade holders and the rotor disc.Control bridge, GRP, for 4 mm ∅...

Référence: 703/41

La palanca acodada, Alu

Référence: 74/7

Rotor head dampers for 2 blade FBL systems

Flybarless electronics have now become common. Where they are being used harder damping is required.For these cases Vario is now offering a harder damping of the blade shaft provided by a pretension absorbing element in the centre block.For the adjustment, the outer O-ring position can be selected between "hard" and "soft" flight characteristics.Important...

Référence: 86

Ball collet 4 mm

Ball collets provide the fixation of double ball-links on the flybar, in order to settle the essential distance to the rocker. Ball collet 4 mm Ø, pack of 2, chrome-plated.

Référence: 832/87

90 degree link

A 90° twisted double ball-link connect the mixer lever to the ball collet on the flybar, suitable for the rotor head 722/72.Content of the package: 2 pieces

Référence: 703/31

3-blade centre piece, 10 mm

Item to a multi-blade rotor head for Ø 10 mm shaft; see Ord.No. 703/30, 704/30 and 705/30.

Référence: 117/3

Spacer washer 10 x 24.6 mm

Spacer washer for rotor headPack of 2

Référence: 72/10

Pièce centrale tête rotor

Rotor head centre piece for 2-bladed rotor head.

Référence: 73/15

Axe porte-pales 8 x 115,9 mm

 Thrust bearing shaft8 Ø x 115.9 mm

Référence: 72/5

Rotor brake, GRP

When you have landed and stopped the engine, the rotor head continues spinning for quite some time until it stops by itself. A rotor brake shortens the time you have to wait. Using light pressure with the flat of your hand on the domed face of the rotor brake you can stop the rotor in a few moments.Please note: stay in safe distance away from the turning...

Référence: 80/30

Bras de commande en métal, 5 mm

Control bridge 2-part metal, for 5 mm ∅ flybar.

Référence: 832/69

Connecting elbow, aluminium

Connecting elbow, aluminiumPack of 2

Référence: 832/82

Rocker, black anodized aluminum

Not available

Référence: 79/15

Barre de Bell inox 4 x 600 mm

The length of the flybar itself also plays an important role in the model's flight characteristics: the longer the flybar, the smoother the hover. A longer flybar increases the control deflections. 450 mm length is considered normal, while 510 mm provides more docile handling.

Référence: 702/92

Rotor head balance weight Bell 47 black

Not available
