Spacer washer for SKS rotor head

Riferimento: 78/41

Mixer lever cranked

Mixer lever, content of the package 1 piece.Additionial accessories for the use of mixer levers are either two flanged ballraces or two flanged bushes from Delrin as a low cost alternative. The screwing on the blade holder arm complies with the kind of hole, i.e. it depends on the through hole or on the blind hole. Please note for choosing the screws:...

Riferimento: 86

Ball collet 4 mm

Ball collets provide the fixation of double ball-links on the flybar, in order to settle the essential distance to the rocker. Ball collet 4 mm Ø, pack of 2, chrome-plated.

Riferimento: 91/55

Lead for paddles

 Lead for paddlespack of 2approx. 8.5 g each

Riferimento: 71/9

PesI per stabilizzatore foro Ø 4 mm

Balance weight ∅ 4 mm approx. 7 g Content of the package 2 pieces

Riferimento: 704/33

4-blade centre piece 12 mm

Component part for a multi-blade rotor head for 12 mm Ø main shaft; see Ord.No. 703/32, 704/32 resp. 705/32.

Riferimento: 79/10

Asta stabilizzatore 4 x 510 mm

The length of the flybar itself also plays an important role in the model's flight characteristics: the longer the flybar, the smoother the hover. A longer flybar increases the control deflections. 450 mm length is considered normal, while 510 mm provides more docile handling.

Riferimento: 87/12

Doble bola-link para Delta rotor

Riferimento: 87/20

Actuating lever

The connection between mixer lever and variable rocker is carried out by an actuating lever, triple ballraced. Content of the package: 2 pieces

Riferimento: 703/41

La palanca acodada, Alu

Riferimento: 702/76

GRP blade holder, 22 mm blade throat

This blade holder was specially developed for the large Bell 47 G III with a rotor diameter of 2.36 m. It has a 22 mm blade throat and a 6 mm Ø bore for the retaining screw, i.e. the matching blade holder screws and self-locking nuts are M6 in size.

Riferimento: 74/14

O-ring 3 x 16 mm soft

O-ring 3 x 16 mm soft Content of the package: 8 pieces Tip: O-rings always slide with a drop of silicone oil onto the shaft.

Riferimento: 91/50

Paletti 105 x 60 mm per Ø 4+ 5 mm

Paddles1 pairapprox. 29 g eachfor ∅ 4 mm / 5 mm flybar

Riferimento: 71/20

Compensatore di passo, VTR

Pitch compensator, complete, for 10 mm ∅ main shaft, centre piece GRP

Riferimento: 72/18

Rotor head centre piece, rigid

Aluminium centre piece, rigid, for 10 mm main shaft

Riferimento: 76/19

GRP blade holder, 5 mm ∅ hole

As demands on helicopters continue to rise, so stronger blade holders are required. In this case a 14 mm blade holder is combined with a 5 mm Ø hole for blade retention, i.e. the matching blade holder screws and self-locking nuts are M5 in size.GRP blade holder with short linkage armfor multi-blade rotor heads

Riferimento: 707/6

Rotor head cover for 4-blade head

Not available
