Collective pitch arms

Reference: 702/76

GRP blade holder, 22 mm blade throat

This blade holder was specially developed for the large Bell 47 G III with a rotor diameter of 2.36 m. It has a 22 mm blade throat and a 6 mm Ø bore for the retaining screw, i.e. the matching blade holder screws and self-locking nuts are M6 in size.

Reference: 832/78

Mixer lever, aluminium

This mixer lever from aluminium matches the dimensions of the rotor head 722/72 (e.g. model Robinson R22) with a max. rotor disc of 2 500 mm.

Reference: 82/30

Rocker kit Bell UH / Bell 212 / Bell 47

Not available

Reference: 10/91

Silicone sleeve 8 x 2 x 100 mm

Content of the package: 1 piece

Reference: 832/71

Pitch mixer centre piece 12 mm

Pitch mixer centre piece, aluminium, 12 mm Ø

Reference: 87/12

Doble bola-link para Delta rotor

Reference: 71/9

Balance weight ∅ 4 mm

Balance weight ∅ 4 mm approx. 7 g Content of the package 2 pieces

Reference: 74/15

O-ring 2.5 x 12 mm, for Elastomer rotor head

Pack of 4Tip: O-rings always slide with a drop of silicone oil onto the shaft.

Reference: 54/16

Clamp ring pitch compensator 17 mm

The 17 mm Ø clamp ring is fitted to the rotor head centre piece, the steel pin slides in the guide slot of the pitch compensator. Rotate the clamp for fine adjustment so that your helicopter flies straight when you apply a pitch-axis command.Clamp ring for pitch compensator 17 mm Ø, length of the pin 30 mm.

Reference: 85/1

Spacer 4 x 6 x 1.5 mm

Spacer 4 x 6 x 1.5 mm, brass Content of the package: 2 pieces

Reference: 71/26

Curved link

Curved link Content of the package: 2 pieces

Reference: 79/30

Flybar stainless steel 5 x 600 mm

The length of the flybar itself also plays an important role in the model's flight characteristics: the longer the flybar, the smoother the hover. A longer flybar increases the control deflections. 450 mm length is considered normal, while 510 mm provides more docile handling.

Reference: 74/18

O-ring 2 x 19 mm soft

O-ring 2 x 19 mm soft Content of the package: 8 pieces Tip: O-rings always slide with a drop of silicone oil onto the shaft.

Reference: 78/40

Mixer lever set

Mixer levers are an essential part of every flybar-controlled rotor head. From the swashplate a pushrod runs to the ballraced mixer arm which is screwed to the blade holder arm. The mixer levers transmit the control movement to the flybar via the double ball-link.Additionial accessories for the use of mixer levers are either two flanged ballraces or two...

Reference: 54/18

Clamp ring for 12 mm

Same design as clamp ring 54/13, but for 12 mm Ø main rotor shaft.Clamp ring for pitch compensator 12 mm Ø, length of the pin 40 mm.

Reference: 72/45

Aluminium centre piece, 12 mm

Aluminium centre piece for 12 mm Ø main shaft
